FINE 604 BATTEN
OVERVIEW
FINE 604 BATTEN is LED moving head effect light. 4 LED RGBW 4-in-1 light sources with 60W power, light source life ≥ 50,000 hours, light output over 3000Lm. With unique optical design, the zoom range is large, 5°~50°; Minimum Angle beam sense is strong, full without cross, large Angle color mixing is excellent; Two-stage zoom system, when the input signal is disconnected, the zoom system automatically retracts to prevent damage during assembly and transportation. Y-axis can rotate Angle 200°; Built-in 100 color macros and 47 effect macros; The product has simple appearance, compact structure, aluminum alloy and engineering plastic shell, small size and light weight; Net weight 10kg, size: 480×120×303mm, very suitable for entertainment, rental, TV stations, schools, weddings, bars, variety programs and other application scenarios.
TECHNICAL SPECIFICATION
LIGHT SOURCE
  • 4 pcs 60W RGBW 4 in 1 LEDs

  • Average Life Span≥ 50,000 h

  • 4 pcs 60W RGBW 4 in 1 LEDs

  • Average Life Span≥ 50,000 h

OPTICAL SYSTEM
  • Beam Angle: 5 °- 50°

  • Glass light guide + High-quality PMMA optical lens

  • Color Temperature: 2700K-8000K

  • Beam Angle: 5 °- 50°

  • Glass light guide + High-quality PMMA optical lens

  • Color Temperature: 2700K-8000K

MOVEMENT PARAMETER
  • Tilt 200°

  • Tilt 200°

CONTROL AND PROGRAMMING
  • Control channel: Stand(14)/RGB(26)/RGBW(30)/ Shape(26)

  • Protocol: DMX512, RDM, sACN, Art-net

  • DMX Connector: 3-pin XLR input/ output (5-pin for option), RJ45 Network input/output

  • USB external power interface

  • Control channel: Stand(14)/RGB(26)/RGBW(30)/ Shape(26)

  • Protocol: DMX512, RDM, sACN, Art-net

  • DMX Connector: 3-pin XLR input/ output (5-pin for option), RJ45 Network input/output

  • USB external power interface

POWER SUPPLY
  • 100-240V~, 50/60Hz

  • Input Power: 280 W

  • PF≥0.98

  • 100-240V~, 50/60Hz

  • Input Power: 280 W

  • PF≥0.98

DIMENSION AND WEIGHT
  • Fixture Dimension:480 x 120 x 303 mm

  • Package Dimension:

    1114 x 586 x 515mm (flight case)

    685 x 590 x 425mm (carton)

  • Net Weight: 10 kg (fixture)

  • Gross Weight: 108kg (flight case) /11kg(carton)

  • Fixture Dimension:480 x 120 x 303 mm

  • Package Dimension:

    1114 x 586 x 515mm (flight case)

    685 x 590 x 425mm (carton)

  • Net Weight: 10 kg (fixture)

  • Gross Weight: 108kg (flight case) /11kg(carton)

IP RATE
  • IP 20
  • IP 20
DIMENSIONS
990712210042 FINE 604 BATTEN Dimension drawing 2024-10-25_00(1)
PHOTOMETRICS

FINE 604 BATTEN(OSRAM光源)英文版-20200601_00

GOBOS & COLORS
OPTIONAL ACCESSORIES
VIDEO
DOWNLOADS
Filename
Size
Uploaded
Downloading
TEKMAND
icon
FINE 604 BATTEN (TEKMAND)
2024-10-21
MA2
icon
FINE 604 BATTEN (MA2)
2024-10-21
Avolites Pearl
icon
FINE 604 BATTEN(Avolites Pearl)
2020-10-19
Avolites D4
icon
FINE 604 BATTEN(Avolites D4)
2021-01-05
MA3 (GDTF)
icon
FINE 604 BATTEN(GDTF)
2021-11-15
DMX chart
Drawings
icon
FINE 604 BATTEN Dimension drawing
2024-10-31
Share
PDFpdf-icon

FINE 604 BATTEN

OVERVIEW
TECHNICAL SPECIFICATION
GOBOS & COLORS
OPTIONAL ACCESSORIES
VIDEO
DOWNLOADS
ENQUIRE
FINE 604 BATTEN
FINE 604 BATTEN is LED moving head effect light. 4 LED RGBW 4-in-1 light sources with 60W power, light source life ≥ 50,000 hours, light output over 3000Lm. With unique optical design, the zoom range is large, 5°~50°; Minimum Angle beam sense is strong, full without cross, large Angle color mixing is excellent; Two-stage zoom system, when the input signal is disconnected, the zoom system automatically retracts to prevent damage during assembly and transportation. Y-axis can rotate Angle 200°; Built-in 100 color macros and 47 effect macros; The product has simple appearance, compact structure, aluminum alloy and engineering plastic shell, small size and light weight; Net weight 10kg, size: 480×120×303mm, very suitable for entertainment, rental, TV stations, schools, weddings, bars, variety programs and other application scenarios.
TECHNICAL SPECIFICATION
LIGHT SOURCE
  • 4 pcs 60W RGBW 4 in 1 LEDs

  • Average Life Span≥ 50,000 h

OPTICAL SYSTEM
  • Beam Angle: 5 °- 50°

  • Glass light guide + High-quality PMMA optical lens

  • Color Temperature: 2700K-8000K

MOVEMENT PARAMETER
  • Tilt 200°

CONTROL AND PROGRAMMING
  • Control channel: Stand(14)/RGB(26)/RGBW(30)/ Shape(26)

  • Protocol: DMX512, RDM, sACN, Art-net

  • DMX Connector: 3-pin XLR input/ output (5-pin for option), RJ45 Network input/output

  • USB external power interface

POWER SUPPLY
  • 100-240V~, 50/60Hz

  • Input Power: 280 W

  • PF≥0.98

DIMENSION AND WEIGHT
  • Fixture Dimension:480 x 120 x 303 mm

  • Package Dimension:

    1114 x 586 x 515mm (flight case)

    685 x 590 x 425mm (carton)

  • Net Weight: 10 kg (fixture)

  • Gross Weight: 108kg (flight case) /11kg(carton)

IP RATE
  • IP 20
DIMENSIONS
990712210042 FINE 604 BATTEN Dimension drawing 2024-10-25_00(1)
PHOTOMETRICS

FINE 604 BATTEN(OSRAM光源)英文版-20200601_00

!
×
